Part #
CS6W-590TB-AG
Manufacturer
Series
Category
Take advantage of our extensive on-site inventory.
For wholesale pricing and availability:
General Information
Manufacturer
Series
Part #
CS6W-590TB-AG
Catalog #
CS6W-590TB-AG
Dimensions
2278 L x 1134 W x 40 H mm
Weight
69.7 Lbs.
Approvals
ISO 9001: 2015
ISO 14001: 2015
ISO 45001: 2018
IEC 62941: 2019
IEC 61215
IEC 61730
UL 61730
IEC 61701
IEC 62716
Technical Specifications
Watts PTC
708
Watts STC
590 W
Cells
144
Technology
N-Type TOPCon
Open Circuit Voltage (Voc)
52.6
Short Circuit Current (Isc)
16.87
Max Power Voltage (Vmpp)
43.5
Max Power Current (Impp)
16.28
Max Current
30 A
Efficiency
22.8
Frame Material
Anodized Aluminum Alloy
Frame Thickness (mm)
40
Frame Color
Silver
Backsheet Material
2.0 mm heat strengthened glass with anti-reflective coating
Connector
T6 or MC4-EVO2 or MC4-EVO2A
Output Cables
4.0 mm² (IEC), 12 AWG (UL)
Temp Coefficient (Pmpp)
-0.29
Temp Coefficient (Voc)
-0.25
Fire Classification (Type)
Type 29
Data Sheets and Collateral
View
Datasheet
CS6W-590TB-AG
