Part #
ELNSM54M-HC-N-450 DC BS-E-J
Manufacturer
Series
Category
Take advantage of our extensive on-site inventory.
For wholesale pricing and availability:
General Information
Manufacturer
Series
Part #
ELNSM54M-HC-N-450 DC BS-E-J
Catalog #
ELNSM54M-HC-N-450 DC BS-E-J
Dimensions
1722 L x 1134 W x 35 H mm
Weight
45.19 Lbs.
Approvals
TS EN 61215
TS EN 61730
IEC 61215
IEC61730
IEC 62804 (PID Free) UL 61730-1
UL 61730-2
ISO 9001:2015
ISO 14001:2015
ISO 45001: 2018
ISO 50001:2018
ISO 27001:2013
ISO 10002:2018
ISO 37001:2016
ISO 26000:2021
Technical Specifications
Watts PTC
340
Watts STC
450 W
Cells
108
Technology
N-Type
Open Circuit Voltage (Voc)
39.70
Short Circuit Current (Isc)
14.31
Max Power Voltage (Vmpp)
33.10
Max Power Current (Impp)
13.61
Max Current
25 A
Efficiency
23.04
Frame Material
Anodized Aluminum Alloy
Frame Thickness (mm)
35
Frame Color
Black
Output Cables
4.0mm², 1350mm(+)/1350mm(-) or customized length
Temp Coefficient (Pmpp)
-0.29
Temp Coefficient (Voc)
-0.25
Fire Classification (Type)
Type 1
Data Sheets and Collateral
View
Datasheet
ELNSM54M-HC-N-450 DC BS-E-J
