Catalog #
HIS-T440NF(BK)
Part #
HIS-T440NF(BK)
Manufacturer
Category
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:
General Information
Dimensions
1722 L x 1134 W x 30 H mm
Weight
53.57 Lbs.
Series
NF (BK)
Approvals
UL 61215
UL 61730
IEC 61215
IEC 61730
ISO 9001
ISO 14001
ISO 45001
Technical Specifications
Watts STC
440 W
Cells
108
Technology
N-Type TOPCon
Open Circuit Voltage (Voc)
40.05
Short Circuit Current (Isc)
15.58
Max Power Voltage (Vmpp)
32.95
Max Power Current (Impp)
14.79
Max Current
30 A
Efficiency
22.53
Frame Material
Anodized Aluminum Alloy
Frame Thickness (mm)
30
Frame Color
Black
Backsheet Material
2.0mm(0.08in) semi-tempered solar glass
Connector
Staubli MC4 genuine Connector/IP68
Output Cables
(+)1,200mm(47.2in), (-)1,200mm(47.2in)
Temp Coefficient (Pmpp)
-0.29
Temp Coefficient (Voc)
-0.25
Fire Classification (Type)
Type 29
