Catalog #
LR5-54HPB-405M
Mfr. Part #
LR5-54HPB-405M
Manufacturer
Category
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:
Technical Specifications
Watts PTC
302.7
Watts STC
405 W
Cells
108
Technology
Monocrystalline
Open Circuit Voltage (Voc)
37.15
Short Circuit Current (Isc)
13.78
Max Power Voltage (Vmpp)
31.18
Max Power Current (Impp)
12.99
Max Current
25 A
Efficiency
20.7
Frame Material
Anodized Aluminum Alloy
Frame Thickness (mm)
30
Frame Color
Black
Connector
MC4
Output Cables
4mm2 Output Cable 1200mm
Temp Coefficient (Pmpp)
-0.34
Temp Coefficient (Voc)
0.265
Fire Classification (Type)
Type 1 or 2
General Information
Dimensions
1722 L x 1134 W x 30 H mm
Weight
20.8 Kg.
Series
Hi-MO 5m
Approvals
IEC 61215
IEC 61730
UL 61730
ISO9001:2015: ISO Quality Management System
ISO14001: 2015: ISO Environment Management System
ISO45001: 2018: Occupational Health and Safety
IEC62941: Guideline for module design qualification and type approval
