Part #
LR5-72HBD-525M DOM
Manufacturer
Category
Take advantage of our extensive on-site inventory.
For wholesale pricing and availability:
General Information
Manufacturer
Part #
LR5-72HBD-525M DOM
Catalog #
LR5-72HBD-525M DOM
Dimensions
2256 L x 1133 W x 35 H mm
Weight
39.5 Kg.
Approvals
IEC 61215
IEC 61730
UL 61730
ISO 9001:2015
ISO 14001:2015
ISO 45001:2018
IEC 62941
Technical Specifications
Watts PTC
392.5
Watts STC
525 W
Cells
144
Technology
Monocrystalline
Open Circuit Voltage (Voc)
49.05
Short Circuit Current (Isc)
13.65
Max Power Voltage (Vmpp)
41.20
Max Power Current (Impp)
12.75
Max Current
30 A
Efficiency
20.3
Frame Material
Anodized Aluminum Alloy
Frame Thickness (mm)
35
Frame Color
Silver
Output Cables
4mm2, +400, -200mm / +- 1400mm
Temp Coefficient (Pmpp)
-0.34
Temp Coefficient (Voc)
-0.265
Fire Classification (Type)
Type 29
Data Sheets and Collateral
View
Datasheet
LR5-72HBD-525M DOM
