Catalog #
EVPV350PK
Mfr. Part #
EVPV350PK
Manufacturer
Category
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:

Technical Specifications

Watts PTC
345.6
Watts STC
350 W
Cells
120
Technology
Monocrystalline
Open Circuit Voltage (Voc)
40.3
Short Circuit Current (Isc)
11.13
Max Power Voltage (Vmpp)
33.1
Max Power Current (Impp)
10.58
Max Current
25 A
Efficiency
19.2
Max System Voltage
1000 V
Frame Material
Anodized Aluminum Alloy
Frame Thickness (mm)
30
Frame Color
Black
Backsheet Material
Plastic film (PET)
Connector
Staubli MC4 PV-KBT4/KST4 (4 mm²)
Output Cables
12AWG(4mm²)
Series Fuse Rating (Amps)
25
Temp Coefficient (Pmpp)
-0.34
Temp Coefficient (Voc)
-0.26
Fire Classification (Type)
Type 2

General Information

Dimensions
1755 L x 1040 W x 30 H mm
Weight
43 Lbs.
Series
EVERVOLT® PK Black
Approvals
UL 61730 |Hailstone 35mm [IEC61215-2:2016]|Fire Type 2 [UL61730]|Salt Mist [IEC 61701]|PID [IEC62804]|Ammonia Resistance [IEC62716]

Datasheets
