Catalog #
SIL 500 HM
Mfr. Part #
SIL 500 HM
Manufacturer
Category
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:
Technical Specifications
Watts PTC
369
Watts STC
500 W
Cells
132
Technology
PERC
Open Circuit Voltage (Voc)
45.78
Short Circuit Current (Isc)
13.48
Max Power Voltage (Vmpp)
38.8
Max Power Current (Impp)
12.89
Max Current
25 A
Efficiency
21
Frame Material
Anodized Aluminum
Frame Thickness (mm)
35
Frame Color
Silver
Backsheet Material
High durability, superior hydrolysis and UV resistance, multi-layer dielectric film, fluorine-free PV white backsheet
Connector
Staubli EVO2
Output Cables
1350 mm, φ 5.7 mm
Temp Coefficient (Pmpp)
-0.36
Temp Coefficient (Voc)
-0.28
Fire Classification (Type)
Type 1
General Information
Dimensions
2098 L x 1133 W x 35 H mm
Weight
57.8 Lbs.
Series
Silfab Commercial
Approvals
UL 61215-1:2017 Ed.1
UL 61215-2:2017 Ed.1
UL 61730-1:2017 Ed.1
UL 61730-2:2017 Ed.1
CSA C22.2#61730-1:2019 Ed.2
CSA C22.2#61730-2:2019 Ed.2
IEC 61215-1:2016 Ed.1
IEC 61215-2:2016 Ed.1
IEC 61730-1:2016 Ed.2
IEC 61730-2:2016 Ed.2
IEC 61701:2020
IEC 62716:2013
CEC Listing
UL Fire Rating: Type 1
