Part #
MSE425SX9Z
Manufacturer
Series
Category
Take advantage of our extensive on-site inventory.
For wholesale pricing and availability:
General Information
Manufacturer
Series
Part #
MSE425SX9Z
Catalog #
MSE425SX9Z
Dimensions
2086L x 1054W x 40H mm
Weight
51.6 LBS
Approvals
UL 61730 / IEC 61215 / IEC 61730 / IEC 61701
Technical Specifications
Watts STC
425 W
Cells
72
Technology
Monocrystalline
Open Circuit Voltage (Voc)
49.04
Short Circuit Current (Isc)
11.42
Max Power Voltage (Vmpp)
39.44
Max Power Current (Impp)
10.78
Max Current
20 A
Efficiency
19.3%
Frame Material
Anodized Aluminum Alloy
Frame Thickness (mm)
40
Frame Color
Black
Connector
MC4 Staubli PV-KBT4-EV0 2/6II-UR and PV- KST4-EVO 2/6II-UR, Renhe RHC2xMzC
Output Cables
1.4 m, Wire 4mm² (12 AWG)
Temp Coefficient (Pmpp)
-0.347%/C
Temp Coefficient (Voc)
-0.261%/C
Fire Classification (Type)
1
Data Sheets and Collateral
View
Datasheet
MSE425SX9Z
